COM-E模块

欣扬的Com Express模块系列,包括ATX规格的嵌入式底板,以及体积小Type 6规格的嵌入式主板。这些嵌入式单板的设计规范严谨。搭配合适的软体激活和系统整合,这些工业单板将摇身一变,成为处理特定任务的嵌入式电脑。

Product
Model
CPU 
Serial 
Ethernet 
Display 
Expansion 
ACM-ICLDE7
Model:
ACM-ICLDE7
CPU:
Xeon® D, LLC, up to 10c/20t CPU
Serial:
2
Ethernet:
1 x Intel I210AT GbE Lan, supports PXE Boot
Display:
Expansion:
32 x PCI-e 3.0 Lanes/4 x PCI-e 3.0 x2 Lanes
ACM-TGLUE0
Model:
ACM-TGLUE0
CPU:
Intel® 11th Core™ I Processor
Serial:
2
Ethernet:
1 x Intel I225LM GbE Lan, supports PXE Boot
Display:
-
Expansion:
4 x PCI-e 3.0 x1
ACM-XD15B7
Model:
ACM-XD15B7
CPU:
Xeon® D1548 (8 Core, 2.0/2.6GHz, 12MB cache, TDP 45W)
Serial:
2
Ethernet:
1 x Intel I210AT GbE Lan, supports PXE Boot / 2 x 10 GbE with KR interface & NC-SI
Display:
-
Expansion:
24 x PCI-e 3.0 Lanes / 7 x PCI-e 2.0 Lanes
ACM-XE21B6
Model:
ACM-XE21B6
CPU:
Intel® Core i7- 9850HE/Xeon 2176M Processor
Serial:
2
Ethernet:
1 x Intel I210AT GbE Lan, supports PXE Boot
Display:
-
Expansion:
16 x PCI-e 3.0 Lanes / 8 x PCI-e 2.0 Lanes
