| Features |
|
● Up to 1.7GHz daul-core ARM Cortex-A55 |
   3.gif) |
| Specification |
| CPU/MCU | NXP i.MX 93, dual Cortex-A55 @1.7 GHz Processor |
| Memory | 2GB DDR4 |
| Storage | 32GB eMMC |
| Power Supply |
| Power Requirement | 5V |
| Environmental and Mechanical |
| Dimension | 3.22“ x1.96“ (82 x 50 mm) |
| Weight | 20 g |
| Operating Temp. | -40 °F ~ 185 °F (-40 °C ~ 85 °C) |
| Storage Temp. | -40 °F ~ 185 °F (-40 °C ~ 85 °C) |
| Operating Humidity | 5% ~ 95% relative humidity, non-condensing |
| Certification |
| Carrier | Planning |
| Interface |
| Serial Port | 2 x 2-Wire + 2 x 4-Wire |
| Ethernet | 2 x Ethernet 10/100/1000 |
| USB | 2 x USB2.0 |
| Display | 1 x HDMI 1.4a 1080P@60 1 x 4 Lane LVDS |
| Ordering Information |
| 2IEC-N321-01 | SOM, NXP i.MX 93, 1.7GHz, 2G RAM, 16GB eMMC |
Specifications are subject to change without notice.
| |
